Yamaha T-MAX TechMax
OVERVIEW
Supported by vast styling and luxurious level of comfort, the TMAX commands a dynamic presence while cruising on the busy city streets or long distance travelling. Equipped in an All-New 562cc engine accompanied by its lightweight chassis for smoother navigation, this sport scooter truly is Luxury in Motion.
|
Engine
| Type |
|
Liquid-cooled, 4-stroke, DOHC, 4-valves, In-Line |
| Cylinders |
|
2 Cylinder |
| Displacement |
|
562 cc |
| Bore x stroke |
|
70.0 mm x 73.0 mm |
| Compression ratio |
|
10.9:1 |
| Maximum power |
|
35.0 kW @ 7,500 rpm |
| Maximum torque |
|
55.7 Nm @ 5,250 rpm |
| Lubrication System |
|
Dry Sump |
| Fuel system |
|
Fuel injection |
| Ignition system |
|
TCI |
| Starter system |
|
Electric |
|
|
Transmission
| Transmission system |
|
V-Belt Automatic |
|
|
Chasis
| Overall length |
|
2,195 mm |
| Overall width |
|
780 mm |
| Overall height |
|
1,415 – 1,525 mm |
| Seat height |
|
800 mm |
| Wheelbase |
|
1,575 mm |
| Minimum Ground Clearance |
|
135 mm |
| Wet weight |
|
220 kg |
| Fuel tank capacity |
|
15.0 L |
|
|
Brakes
| Front brake |
|
Hydraulic dual disc brake |
| Rear brake |
|
Hydraulic single disc brake |
|
|
Suspension
| Front Suspension Type |
|
Telescopic forks |
| Rear Suspension Type |
|
Swingarm (link suspension) |
|
|
Tires
| Front Tyre |
|
120/70R15M/C 56H Tubeless |
| Rear Tyre |
|
160/60R15M/C 67H Tubeless |
|
POWER GREY
DARK PETROL
